Giant  |  SKU: 9031023104

Giant Defy Advanced 2 (2026)

$3,79900
Colour: Abyss Black
Size

Pickup in-store only. Shipping not available.
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay

Sizing Chart

Sizing and Geometry

Giant Defy

Sizing chart to be used as a reference only. The best way to determine your size is to visit us in-store and get fitted.

Frame size Rider Height Rider Height (cm)
XS 5'2"-5'6" 157-169
S 5'5"-5'9" 165-175
M 5'7"-5'11" 171-181
ML 5'10"-6'2" 177-187
L 6'0"-6'4" 183-193
XL 6'2"-6'6" 189-199



Geometry

bike diagram with measurements referenced in table that follows

    XS S M ML L XL
A Seat Tube Length (inch) 16.1 17.5 18.9 20.3 21.1 22.2
B Seat Tube Angle 74.5° 74.0° 73.5° 73.0° 73.0° 73.0°
C Top Tube Length (inch) 20.3 20.9 21.5 22 22.6 23.4
D Head Tube Length (inch) 4.7 5.5 5.9 6.9 7.7 8.5
E Head Tube Angle 70.5° 71.8° 72.5° 72.5° 72.5° 72.5°
F Fork Rake (inch) 2 2 2 2 2 2
G Trail (inch) 2.8 2.5 2.3 2.3 2.3 2.3
H Wheelbase (inch) 39.2 39.1 39.3 39.8 40.4 40.9
I Chain Stay Length (inch) 16.5 16.5 16.5 16.5 16.5 16.5
J Bottom Bracket Drop (inch) 3 3 3 2.8 2.8 2.8
K Stack (inch) 20.7 21.3 22 22.7 23.5 24.2
L Reach (inch) 14.5 14.8 15 15.1 15.5 15.8
M Stand Over Height (inch) 27.8 28.9 30 31.3 32 33.1
O Stem Length (inch) 3.1 3.5 3.9 3.9 4.3 4.3
P Crank Length (inch) 6.7 6.7 6.8 6.8 6.9 6.9
Q Wheel Size 700C 700C 700C 700C 700C 700C

Shipping Information

Certain bike brands cannot be shipped and are only available for Click and Collect.

These include but are not limited to the following brands: Giant, GT, Liv, Momentum and Mongoose.

For all other brands, we can provide a shipping quote to your postcode. Please contact us by email at staff@ivanhoecycles.com.au, or text us on 0417 122 950.

Fully assembled when you Click & Collect in-store
Buy Now, Pay Later with ZIP
Free service adjustment within first 6 months

With effortless efficiency and quiet compliance, this lightweight endurance road machine helps you ride stronger and longer. The composite frame and purpose-built components smooth out rough roads and minimise fatigue.

Functional simplicity

Free of cumbersome gimmickry, the frameset is one of the lightest in its category. With a perfect balance of high-performance reactivity and all-day comfort, it offers a “less is more” experience for modern endurance road riding.

Engineered compliance

Advanced-grade composite frame and fork are specifically engineered for endurance road riding, delivering a smooth and efficient ride quality that minimises fatigue on long rides. The new D-Fuse components work together to further absorb road shocks and vibrations.

Total control

New Contact D-Fuse handlebar features ergonomic shaping and an 8-degree flare for comfort and control on all-day rides. Wide, alloy rims are optimised for high-volume tubeless tyres (up to 38mm), providing predictable handling and stability from asphalt to cobbles.

SPECIFICATIONS

Sizes XS, S, M, M/L, L, XL
Colours Abyss Black/Chrome
Frame Advanced-grade Composite, 12x142mm thru-axle, disc
Fork Advanced-grade Composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
Handlebar Giant Contact SL D-Fuse XS:38/41cm, S:38/41cm, M:40/43cm, M/L:40/43cm, L:42/45cm, XL:42/45cm
Grips Stratus Lite 3.0
Stem Giant Contact AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm
Seatpost Giant D-Fuse, composite, 14mm offset
Saddle Giant Approach
Pedals N/A
Shifters Shimano 105
Front Derailleur Shimano 105
Rear Derailleur Shimano 105
Brakes Shimano 105 hydraulic, Shimano SM-RT64 [F]160mm, [R]160mm
Brake Levers Shimano 105
Cassette Shimano 105, 12-speed, 11x36
Chain KMC X12L-1
Crankset Shimano 105, 34/50 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm
Bottom Bracket Shimano, press fit
Rims Giant P-R1, [F]30mm, [R]30mm
Hubs Giant alloy, 12mm thru-axle
Spokes Sapim
Tires Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding
Extras Tubeless prepared, 38mm max tyre size
Max Tyre Clearance 38mm
Weight The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Giant Defy Advanced 2 (2026)

$3,79900

Colour

Size

  • XS
  • S
  • M
  • ML
  • L
  • XL

Motor

N/A

Controller

N/A

Display

N/A

Battery

N/A

Charger

N/A

Sizes

N/A

Frame material

Carbon

Frame

Advanced-grade Composite, 12x142mm thru-axle, disc

Fork

Advanced-grade Composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc

Handlebar

Giant Contact SL D-Fuse XS:38/41cm, S:38/41cm, M:40/43cm, M/L:40/43cm, L:42/45cm, XL:42/45cm

Grips

N/A

Bar Tape

Stratus Lite 3.0

Headset

N/A

Stem

Giant Contact AeroLight XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm

Seatpost

Giant D-Fuse, composite, 14mm offset

Saddle

Giant Approach

Pedals

N/A

Shifters

Shimano 105

Front Derailleur

Shimano 105

Rear Derailleur

Shimano 105

Brakes

Shimano 105 hydraulic, Shimano SM-RT64 [F]160mm, [R]160mm

Brake Levers

Shimano 105

Cassette/Freewheel

Shimano 105, 12-speed, 11x36T

Chain

KMC X12L-1

Crankset

Shimano 105, 34/50 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm

Bottom Bracket

Shimano, press fit

Rims

Giant P-R1, [F]30mm, [R]30mm

Hubs

Giant alloy, 12mm thru-axle

Spokes

Sapim

Tyres

Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding

Wheel Size

N/A

Extras

Tubeless prepared, 38mm max tyre size
