Giant  |  SKU: 6461001104

Giant Reign Advanced E+ 1 (2026)

$12,99900
Colour: Mercury/Carbon Smoke
Size

Special Order: This product will be ordered from our supplier upon purchase and available for collection within 7-14 business days. Read T&Cs here.

  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay

Fully assembled when you Click & Collect in-store
Buy Now, Pay Later with ZIP
Free service adjustment within first 6 months

Sizing Chart

Sizing and Geometry

Giant Reign Advanced E+

Sizing chart to be used as a reference only. The best way to determine your size is to visit us in-store and get fitted.

Sizing Rider Height (cm)
S 163 – 174
M 171 – 182
L 179 – 190
XL 187 – 199


Geometry

bike diagram with measurements referenced in table that follows

    S M L XL
    LO | MD | HI LO | MD | HI LO | MD | HI LO | MD | HI
A Seat Tube Length (mm) 400 425 450 475
A1 Seat Post Insertion Depth (mm) 235 260 285 310
B Seat Tube Angle 77.1° | 77.5° | 77.9° 77.1° | 77.5° | 77.9° 77.1° | 77.5° | 77.9° 77.1° | 77.5° | 77.9°
C Top Tube Length (mm) 570 | 569 | 568 570 | 569 | 568 570 | 569 | 568 570 | 569 | 568
D Head Tube Length (mm) 95 105 120 135
E Head Tube Angle 63.1° | 63.5° | 63.9° 63.1° | 63.5° | 63.9° 63.1° | 63.5° | 63.9° 63.1° | 63.5° | 63.9°
F Fork Rake/Offset (mm) 44 44 44 44
G Trail (mm) 133.3 | 130.3 | 127.4 133.3 | 130.3 | 127.4 133.3 | 130.3 | 127.4 133.3 | 130.3 | 127.4
H Wheelbase (mm) 1226 | 1226 | 1227 1226 | 1226 | 1227 1226 | 1226 | 1227 1226 | 1226 | 1227
I Chain Stay Length (mm) 450 450 450 450
J Bottom Bracket Drop (mm) 10 | 5 10 | 5 10 | 5 10 | 5
K Stack (mm) 647 | 645 | 642 656 | 654 | 651 669 | 667 | 665 683 | 680 | 678
L Reach (mm) 426 | 430 | 435 456 | 460 | 465 476 | 480 | 485 505 | 510 | 514
O Stem Length (mm) 40 40 40 40
P Crank Length (mm) 160 160 160 6.7
Q Wheel Size 29" [F] 27.5" [R] 29" [F] 27.5" [R] 29" [F] 27.5" [R] 29" [F] 27.5" [R]

Bike Shipping

Delivery is available upon specific request for our special order bikes.

Bikes may only be shipped directly to a qualified bike mechanic or bike shop of your choosing, who must complete the assembly of the bike. We strictly cannot ship an unbuilt bike direct to consumer.

The buyer is responsible for all shipping and assembly costs, and is responsible for arranging assembly with their nominated bike store or mechanic.

To request a shipping quote, please submit a request and include the delivery postcode, business name of your nominated bike shop or bike mechanic, and the exact model & frame size of the bike.

Please note: All bikes sold by Ivanhoe Cycles must be assembled by a qualified mechanic or bike shop. Any assembly undertaken without professional assistance is at the customer's risk and any injury as a result of the build without professional assistance will not be covered by the warranty.

Assembly

Every bike purchased or collected in-store at Ivanhoe Cycles is fully assembled by our qualified mechanics free of charge.

Bikes ordered online for shipping* will require partial assembly, including but not limited to: installing handlebar, seatpost, front wheel; adjusting gears and brakes; tuning suspension; installing accessories or bar tape.

Disclaimer: Ivanhoe Cycles strongly advises having your assembly completed by an experienced bicycle mechanic. Any assembly undertaken without professional assistance is at the customer's risk and any injury as a result of the build without professional assistance will not be covered by the warranty.

*Shipping is restricted to certain brands due to assembly requirements.

Returns / Cancellations

If your special ordered item arrives faulty, damaged, or is differently than described, you are entitled to a full refund or replacement.

Cancellations and returns are not accepted on special orders if the consumer:
- changed their mind
- found the item cheaper elsewhere
- decided they didn't like the purchase or had no use for it
- ordered the wrong item

Contact us with any product enquiries you have prior to purchasing.

For more information, please read our Special Order terms and conditions.

Everything about the new Reign Advanced E+ is designed to make it the best descending E-MTB ever. From the bottomless feeling Maestro suspension with 170mm of rear travel (and a 180mm fork) to the punchy new SyncDrive Pro 3 motor and its lightweight, stiff and ultra-adjustable composite frame. We added a titanium skid plate, robust frame protection, and an innovative bash-guard with an elastomer damper—so you can send it with confidence on the most rugged, technical terrain.

DOMINANT ON DESCENTS

Featuring a modified Maestro suspension system with a new integrated lower link and 170mm of rear travel paired with a 180mm fork, this is best descending E-bike ever from Giant. Maestro’s floating pivot design means it’s always active and efficient under pedalling. Its progressive leverage curve makes the rear shock is easy to compress at the top of the stroke and super-supportive near the end range, producing a plush, bottomless feel that uses every bit of its travel. The result is unmatched confidence and control for big hits, steep drops and technical rock gardens.

LIGHTWEIGHT YET POWERFUL

Upgrading from a 36-volt to 48-volt system results in better performance with reduced heat and energy loss. With 90Nm of torque and 800 watts of peak power, the new SyncDrive Pro 3 motor lets you sustain a high torque level, even at higher pedalling cadences—so you feel powerful, consistent support in any riding situation The added power combined with a lighter composite frame and overall weight of just 22.3kg (size medium) means the Reign E+ Advanced packs a punch when you need it most. And the 48-volt system also produces less stress on the EnergyPak 560 battery, which has a nearly endless lifespan of up to 2300 charge cycles.

PREMIUM PROTECTION

Designed to shred hard and take a beating, the Reign Advanced E+ features a tough, dual-density battery cover that doubles as a full-length protector on the underside of the down tube—perfect for chairlifts, trailers or pickup truck shuttles. A new integrated skid plate protects the motor with corrosion resistant titanium that’s twice as strong as aluminium. And with less friction, the skid plate also helps keep you from getting hung up on rocks, roots, or other obstacles. Finally, a unique MRP active bash-guard, with an elastomer damper and suspended design, gives you unmatched chain and chainring protection.

BATTERY RANGE

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

  • Extreme conditions: 45 km
  • Good conditions: 90 km
  • Ideal conditions: 160 km

Giant Reign Advanced E+ 1 (2026)

$12,99900

Colour

Size

  • S
  • M
  • L
  • XL

Motor

Giant SyncDrive Pro 3, 48v, 90Nm, 800W max power, powered by Yamaha

Controller

RideControl Ergo 4, grip integrated

Display

RideControl GO LUX, frame integrated LED display ANT+

Battery

EnergyPak Smart 560Wh EnergyPak Plus 280 range extender compatible

Charger

Giant EnergyPak smart charger 4A, 48V

Sizes

N/A

Frame material

Carbon

Frame

Advanced-grade composite, Advanced Forged Composite Upper Rocker, 170mm Maestro suspension system, flip chip, UDH hanger 12x148mm thru-axle

Fork

Fox 38 Performance Elite E-Tuned, 180mm travel, 44mm offset, GRIP X2 damper, Boost Kabolt-X 110x15mm

Handlebar

Giant Contact Enduro, 35mm rise

Grips

Giant Tactal Pro-E, single lock-on

Bar Tape

N/A

Headset

N/A

Stem

Giant Contact SL 35mm S:40mm, M:40mm, L:40mm, XL:40mm

Seatpost

Giant Contact Switch travel-adjustable dropper, remote S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 170-200mm travel / 30.9 x 530mm XL: 170-200mm travel / 30.9 x 530mm

Saddle

Giant Romero

Pedals

N/A

Shifters

SRAM Eagle 90, 1x12

Front Derailleur

N/A

Rear Derailleur

SRAM Eagle 90 T-Type

Brakes

TRP DH-R EVO DH, hydraulic, TRP rotors [F]220mm, [R]220mm

Brake Levers

TRP DH-R EVO

Cassette/Freewheel

SRAM XS-1270, T-Type 10x52T

Chain

SRAM Eagle 70 T-Type

Crankset

Praxis e-HD crank arms SRAM Eagle T-Type steel direct mount, 36T chain ring S:160mm, M: 160mm, L:160mm, XL:160mm

Bottom Bracket

N/A

Rims

Giant E-TRA Hookless Tubeless ready Alloy 29" [F] 27.5" [R] 30mm inner width

Hubs

Giant E-TRX MTB Alloy Hub, 6 Bolt, 110x15 [F] / 148x12 SRAM XD Drive Body Pawl Driver (6 Pawl 72T) Thru-axle [R]

Spokes

Sapim Laser, e-bike optimised

Tyres

Maxxis Assagai 29x2.5" foldable, Tubeless, EXO+, 3C MaxxGrip [F] Maxxis Minion DHR II 27.5x2.4" foldable, Tubeless, DoubleDown, 3C MaxxGrip Compound [R]

Wheel Size

N/A

Extras

Tyre Pressure Management System, Torx 25 Battery Lock with built-in Torque limiter, Tubeless kit (liquid, valves, levers, manual, tool), MRP E-Amg, custom bashguard with integrated damping design
