Liv | SKU: 6029032103

Liv Intrigue X Advanced E+ Elite 3 Women's Electric Mountain Bike (2024)

$7,499⁰⁰ ~~$8,999⁰⁰~~

Giant SyncDrive Pro2 85Nm motor with 400Wh battery
Advanced-Grade Composite front triangle | 140mm travel
Marzocchi Bomber Z2 E-Tuned fork | 150mm travel
Fox DPS Performance shock
Shimano Deore 12-speed drivetrain

Colour: Shoreline

A Liv Intrigue X Advanced E+ EL 3 electric mountain bike with a light blue frame and black accents, featuring a front suspension fork, rear suspension, and a chain drive system.

XS S M L

Product variants

Special Order: This product will be ordered from our supplier upon purchase and available for collection within 7-14 business days. Read T&Cs here.

Fully assembled when you Click & Collect in-store

Buy Now, Pay Later with ZIP

Free service adjustment within first 6 months

Sizing Chart

Sizing and Geometry

Liv Intrigue X E+

Sizing chart to be used as a reference only. The best way to determine your size is to visit us in-store and get fitted.

Sizing	Rider Height	Rider Height (cm)
XS	5"0" - 5'4"	152 - 163
S	5′2″ – 5′7″	158 – 169
M	5′5″ – 5′9″	164 – 175
L	5'7" - 5'11"	170 - 181

Geometry

bike diagram with measurements referenced in table that follows

		XS	S	M	L
		LOW \| HIGH	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH
A	Seat Tube Length (mm) (inch)	38015	40015.7	42516.7	45017.7
B	Seat Tube Angle (degrees)	77.2° \| 78.0°	77.2° \| 78.0°	76.0° \| 76.7°	76.0° \| 76.7°
C	Top Tube Length (mm) (inch)	55721.9 \| 55521.9	57222.5 \| 57022.4	59723.5 \| 59523.4	62224.5 \| 62024.4
D	Head Tube Length (mm) (inch)	953.7	953.7	1003.9	1154.5
E	Head Tube Angle (degrees)	65.7° \| 66.5°	65.7° \| 66.5°	65.8° \| 66.5°	65.8° \| 66.5°
F	Fork Rake (mm) (inch)	441.7	441.7	441.7	441.7
G	Trail (mm) (inch)	1134.4 \| 1084.3	1134.4 \| 1084.3	1134.4 \| 1084.3	1134.4 \| 1084.3
H	Wheelbase (mm) (inch)	117446.2 \| 117546.3	118846.8 \| 119046.9	120047.2 \| 120147.3	122848.3 \| 122948.4
I	Chain Stay Length (mm) (inch)	44717.6 \| 44717.6	44717.6 \| 44717.6	44717.6 \| 44717.6	44717.6 \| 44717.6
J	Bottom Bracket Drop (mm) (inch)	301.2 \| 200.8	301.2 \| 200.8	301.2 \| 200.8	301.2 \| 200.8
K	Stack (mm) (inch)	60623.9 \| 60123.7	60623.9 \| 60123.7	61124.1 \| 60523.8	62524.6 \| 61924.4
L	Reach (mm) (inch)	41916.5 \| 42716.8	43417.1 \| 44217.4	44417.5 \| 45217.8	46618.3 \| 47318.6
M	Stand Over Height (mm) (inch)	72228.4 \| 73028.7	72628.6 \| 73528.9	71728.2 \| 72628.6	71128 \| 72328.5
O	Stem Length (mm) (inch)	401.6	401.6	401.6	502
P	Crank Length (mm) (inch)	1606.3	1606.3	1656.5	1656.5
Q	Wheel Size	R27.5" / F	R27.5" / F	R27.5" / F	R27.5" / F

Bike Shipping

Delivery is available upon specific request for our special order bikes.

Bikes may only be shipped directly to a qualified bike mechanic or bike shop of your choosing, who must complete the assembly of the bike. We strictly cannot ship an unbuilt bike direct to consumer.

The buyer is responsible for all shipping and assembly costs, and is responsible for arranging assembly with their nominated bike store or mechanic.

To request a shipping quote, please submit a request and include the delivery postcode, business name of your nominated bike shop or bike mechanic, and the exact model & frame size of the bike.

Please note: All bikes sold by Ivanhoe Cycles must be assembled by a qualified mechanic or bike shop. Any assembly undertaken without professional assistance is at the customer's risk and any injury as a result of the build without professional assistance will not be covered by the warranty.

Assembly

Every bike purchased or collected in-store at Ivanhoe Cycles is fully assembled by our qualified mechanics free of charge.

Bikes ordered online for shipping* will require partial assembly, including but not limited to: installing handlebar, seatpost, front wheel; adjusting gears and brakes; tuning suspension; installing accessories or bar tape.

Disclaimer: Ivanhoe Cycles strongly advises having your assembly completed by an experienced bicycle mechanic. Any assembly undertaken without professional assistance is at the customer's risk and any injury as a result of the build without professional assistance will not be covered by the warranty.

*Shipping is restricted to certain brands due to assembly requirements.

Returns / Cancellations

If your special ordered item arrives faulty, damaged, or is differently than described, you are entitled to a full refund or replacement.

Cancellations and returns are not accepted on special orders if the consumer:
- changed their mind
- found the item cheaper elsewhere
- decided they didn't like the purchase or had no use for it
- ordered the wrong item

For more information, please read our Special Order terms and conditions.

Sizing and Geometry

Liv Intrigue X E+

Sizing chart to be used as a reference only. The best way to determine your size is to visit us in-store and get fitted.

Sizing	Rider Height	Rider Height (cm)
XS	5"0" - 5'4"	152 - 163
S	5′2″ – 5′7″	158 – 169
M	5′5″ – 5′9″	164 – 175
L	5'7" - 5'11"	170 - 181

Geometry

		XS	S	M	L
		LOW \| HIGH	LOW \| HIGH	LOW \| HIGH	LOW \| HIGH
A	Seat Tube Length (mm) (inch)	38015	40015.7	42516.7	45017.7
B	Seat Tube Angle (degrees)	77.2° \| 78.0°	77.2° \| 78.0°	76.0° \| 76.7°	76.0° \| 76.7°
C	Top Tube Length (mm) (inch)	55721.9 \| 55521.9	57222.5 \| 57022.4	59723.5 \| 59523.4	62224.5 \| 62024.4
D	Head Tube Length (mm) (inch)	953.7	953.7	1003.9	1154.5
E	Head Tube Angle (degrees)	65.7° \| 66.5°	65.7° \| 66.5°	65.8° \| 66.5°	65.8° \| 66.5°
F	Fork Rake (mm) (inch)	441.7	441.7	441.7	441.7
G	Trail (mm) (inch)	1134.4 \| 1084.3	1134.4 \| 1084.3	1134.4 \| 1084.3	1134.4 \| 1084.3
H	Wheelbase (mm) (inch)	117446.2 \| 117546.3	118846.8 \| 119046.9	120047.2 \| 120147.3	122848.3 \| 122948.4
I	Chain Stay Length (mm) (inch)	44717.6 \| 44717.6	44717.6 \| 44717.6	44717.6 \| 44717.6	44717.6 \| 44717.6
J	Bottom Bracket Drop (mm) (inch)	301.2 \| 200.8	301.2 \| 200.8	301.2 \| 200.8	301.2 \| 200.8
K	Stack (mm) (inch)	60623.9 \| 60123.7	60623.9 \| 60123.7	61124.1 \| 60523.8	62524.6 \| 61924.4
L	Reach (mm) (inch)	41916.5 \| 42716.8	43417.1 \| 44217.4	44417.5 \| 45217.8	46618.3 \| 47318.6
M	Stand Over Height (mm) (inch)	72228.4 \| 73028.7	72628.6 \| 73528.9	71728.2 \| 72628.6	71128 \| 72328.5
O	Stem Length (mm) (inch)	401.6	401.6	401.6	502
P	Crank Length (mm) (inch)	1606.3	1606.3	1656.5	1656.5
Q	Wheel Size	R27.5" / F	R27.5" / F	R27.5" / F	R27.5" / F

Liv Intrigue X Advanced E+ Elite 3 Women's Electric Mountain Bike (2024)

Next-level performance and unforgettable fun await you on this premium e-MTB. The cutting-edge Intrigue X Advanced E+ Elite is remarkably light yet super powerful. Get ready to feel like a pro as you shred technical terrain with confidence, accelerate up climbs, and corner at top speed.

Lightweight and nimble

This full-suspension E-MTB, with its short chainstay and 140mm (rear)/150mm (front) travel, is engineered to create an ultra-light, efficient and responsive ride. Exceptional shock absorption is an added bonus on rock gardens.

Powerful and smooth

A potent 85Nm of torque delivered by the lightweight SyncDrive Pro 2 Mg motor is smooth and instant, keeping you efficient and in control at all times. The ultra-slim, 400Wh battery hidden in the down tube minimises weight and provides a perfect balance of efficiency and range.

Sleek design

From the integrated control unit to the sleek console on the top tube and the internal cable routing, every design element embodies a high-end, modern look. It combines leading-edge E-MTB design with a user-friendly experience.

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

Conditions are categorised as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

Conditions	Range
Extreme	35km
Good	70km
Ideal	130km

Motor

Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
Controller

Giant RideControl Ergo3, grip integrated remote
Display

RideControl GO, frame integrated LED display ANT+ Wireless display compatible
Battery

EnergyPak Smart 400Wh EnergyPak Plus, Giant EnergyPak Plus 200 range extender compatible
Frame material

Carbon
Frame

Advanced-Grade Composite front triangle, ALUXX SL-Grade rear triangle, 140mm Maestro suspension , flip chip, UDH hanger 12x148mm thru-axle
Fork

Marzocchi Bomber Z2 E-Tuned, 29er, 150mm travel, 44mm offset, RAIL damper Sweep-Adj, Kabolt 110
Shock

Fox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, custom tuned
Handlebar

Giant Contact 35 Trail, 35mm
Grips

Liv Tactal Pro-E Single Lock-On Grips
Stem

Giant Contact SL 35
Seatpost

TranzX travel-adjustable dropper, remote XS: 90-125mm travel / 30.9 x 409mm S: 90-125mm travel / 30.9 x 409mm M: 140-170mm travel / 30.9 x 459mm L: 140-140mm travel / 30.9 x 499mm
Saddle

Liv Sylvia E+
Pedals

N/A
Shifters

Shimano Deore
Front Derailleur

MRP HD2 co-moulded chain guide
Rear Derailleur

Shimano Deore 12-speed, Shadow+
Brakes

Shimano BR-MT420, 4-piston, hydraulic disc, 203mm
Brake Levers

Shimano Deore, I-spec EV
Cassette/Freewheel

Shimano CS-M6100-12, 10-51T, 12-speed
Chain

KMC e.12 Turbo, EcoProteq, e-bike optimized
Crankset

Praxis Wave 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set XS:160mm, S: 160mm, M: 165mm, L:165mm
Rims

Giant AM, alloy 29" [F], 27.5" [R]
Hubs

Shimano MT410 Boost, Center-Lock, 110x15 [F] 148x12 Shimano Micro-Spline Drive Body Thru-axle [R]
Spokes

Sapim E-Lite [R] Race [F], e-bike optimised
Tyres

Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
Extras

Tubeless kit (liquid, valves, levers) Inner tube supplied
Notes

Please note that, based on component availability and other factors, specifications are subject to change without notice.
Speeds (rear)

12 Speed
Age Group

Adults, Teenagers
Gender

Womens
Discipline

Electric, Mountain
SKUs

Shoreline/XS: 6029032103, Shoreline/S: 6029032104, Shoreline/M: 6029032105, Shoreline/L: 6029032107
