Orbea  |  SKU: M12451B7

Orbea Orca M20i Team (2022)

$4,09900 $7,99900
Colour: Raw Carbon/Titanium
Size

Shipping options available.
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay

Sizing Chart

Sizing and Geometry

Orbea Orca

Sizing chart to be used as a reference only. The best way to determine your size is to visit us in-store and get fitted.

Size Rider Height (cm)
47cm 155-160cm
49cm 160-166cm
51cm 167-172cm
53cm 173-179cm
55cm 180-185cm
57cm 186-191cm
60cm 192-207cm


Geometry

AVANT H30

Specification 47 49 51 53 55 57 60
Seat Tube (mm) 440 460 480 500 520 540 570
Top Tube (mm) 510.3 522.7 535.9 548.5 560.4 576 590
Head Tube (mm) 110.5 118.2 134.6 153 173 191.2 218.3
Head Angle (°) 71° 71.5° 72.2° 72.8° 73° 73.2° 73.2°
Seat Angle (°) 74.5° 74° 73.7° 73.5° 73.5° 73.2° 73.2°
Chainstay (mm) 408 408 408 408 408 408 408
Wheelbase (mm) 971.8 975.4 980 981.2 991.4 1001.9 1015.6
Stack (mm) 506 515 533 552 572 590 616
Reach (mm) 370 375 380 385 391 398 392

Shipping Information

This product: Shipping options available.

Shipping available†

We offer shipping on select brands including: Rocky Mountain, Orbea, XDS, Icon, Jamis, Shogun, Schwinn, BYK, Kidvelo. These bikes are shipped unbuilt in their original box.

†Only bikes stocked at our Warehouse location are available for shipping.

Shipping upon request to your local bike shop

Some brands require the bike is delivered directly to a bicycle shop or mechanic for assembly, and shipping is not available to your residence. These include GT, Cannondale, .

Request a shipping quote to proceed.

Pickup in-store only

Certain bike brands cannot be shipped and are only available for Click and Collect or purchase in-store.

These include but are not limited to the following brands: Giant, Norco, Liv, Momentum, Malvern Star and Mongoose.

Pre-assembled bikes

†Any bikes in stock at our Heidelberg Heights, Hallam or Hoppers Crossing store locations are already fully assembled, and therefore only available for Click and Collect or purchase in-store.

Fully assembled when you Click & Collect in-store
Buy Now, Pay Later with ZIP
Free service adjustment within first 6 months

Orbea Orca M20i Team (2022)

The Orca M20i Team is ideal for riders seeking a new endurance road bike with the latest 12-speed Shimano Ultegra Di2 electronic gears and excellent wheels. It suits those upgrading from an aluminium road bike, a very old carbon one, or buying their first performance road bike.

The Frame

ORCA stands for “ORbea” and “CArbon.” Every Orca is hand-built and hand-painted in Spain. OMR stands for endurance and OMX for race. The OMR frame delivers 10% higher vibration absorption than the OMX frame.

OMR Carbon Tubing

These shapes have been specifically constructed for comfort, smooth ride feel, and efficiency. The OMR frame weight is 1,030 grams (size 53).

OMR Ergonomics

The Orca OMR is more comfortable due to its physical tube profiles and how the rider sits on the bike. It is 7mm higher at the front and 3mm shorter than the Orca OMX for a size 53 (medium).

The M20iTEAM Build

The M20iTEAM is equipped with the latest 12-speed Shimano Ultegra Di2 hydraulic disc brake groupset, which includes significant changes like wireless shifters and built-in Bluetooth.

Orbea Orca M20i Team (2022)

From $4,09900 $7,99900

Colour

Size

  • 51cm
  • 53cm

Motor

N/A

Controller

N/A

Display

N/A

Battery

N/A

Charger

N/A

Sizes

N/A

Frame material

Carbon

Frame

Orbea Orca carbon OMR Disc, monocoque construction, HS 1,5”, BB 386mm, power meter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, Speed release compatible dropout, Internal Cable Routing, EC/DC compatible

Fork

Orbea carbon fork 2021, aluminium steerer, 1-1/8” head tube

Handlebar

OC RP20 Road Performance SL // Reach 80 // Drop 125, w/Di2 hole

Grips

N/A

Bar Tape

N/A

Headset

N/A

Stem

OC RP10 Road Performance ICR // -8º // IFC02 computer mount interface

Seatpost

Orbea OC2 // Carbon 27.2 // Offset 20mm

Saddle

Prologo Scratch-M5 Pas T2.0 size 140mm

Pedals

N/A

Shifters

Shimano ST-8170, 2x12 speed

Front Derailleur

Shimano Ultegra Di2 R8150

Rear Derailleur

Shimano Ultegra Di2 R8150

Brakes

Shimano Ultegra R8170 hydraulic disc

Brake Levers

Shimano Ultegra R8170 hydraulic

Cassette/Freewheel

Shimano Ultegra R8100 11-30T, 12 speed

Chain

Shimano M8100

Crankset

Shimano Ultegra R8100 34/50T

Bottom Bracket

Shimano press fit

Rims

FULCRUM Racing 600 DB

Hubs

FULCRUM Racing 600 DB

Spokes

FULCRUM Racing 600 DB

Tyres

Vittoria Rubino IV G2.0 Foldable 700x28c

Wheel Size

N/A

Extras

N/A
