Rocky Mountain Instinct Powerplay A30 Alloy (2023)
Motor: Dyname 4.0 | 108 N·m | 720 Wh
Rocky Mountain Instinct Powerplay A30 Alloy (2023) - Blue/Black / S is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Shipping Information
Shipping Information
Certain bike brands cannot be shipped and are only available for Click and Collect.
These include but are not limited to the following brands: Giant, GT, Liv, Momentum and Mongoose.
For all other brands, we can provide a shipping quote to your postcode. Please contact us by email at staff@ivanhoecycles.com.au, or text us on 0417 122 950.
Mountain Bikes
| Rider Height (cm) | |||||
| MODEL | XS | S | M | L | XL |
| Soul 10 | 152-165 | 160-170 | 167-180 | 177-188 | - |
| Instinct Alloy (27.5) | 142-158 | 155-168 | - | - | - |
| Instinct Alloy (29) | - | 157-170 | 167-178 | 175-188 | 185-198 |
| Instinct Carbon | 147-158 | 152-167 | 162-178 | 172-188 | 183-198 |
| Altitude Alloy (27.5) | - | 155-168 | 165-175 | - | - |
| Altitude Alloy (29) | - | - | 167-178 | 175-188 | 185-198 |
| Altitude Carbon | - | 152-167 | 162-178 | 172-188 | 183-198 |
| Element | 142-158 | 157-170 | 167-178 | 175-188 | 185-198 |
| Slayer | - | 155-168 | 165-178 | 175-188 | 185-198 |
POWERPLAY // Electric Mountain Bikes
| Rider Height (cm) | |||||
| MODEL | XS | S | M | L | XL |
| Instinct Powerplay | - | 157-170 | 167-178 | 175-188 | 185-198 |
| Altitude Powerplay | - | 157-170 | 167-178 | 175-188 | 185-198 |
Rocky Mountain Instinct Powerplay A30 Alloy (2023)
Rocky Mountain Instinct Powerplay A30 Alloy (2023)
The Instinct Powerplay is built for exploration. Versatile geometry, dialled kinematics, and powered by Rocky's Dyname 4.0 drive system, you’ll be riding bigger days than ever before.
- Torque: 108Nm
- Battery Size: 720Wh
- Motor: Dyname 4.0
- Suspension Travel: [F] 150mm [R] 140mm
Dyname™ 4.0, only available on Rocky Mountain Powerplay, is incredibly powerful and is truly a leader among e-bike motors.
Rocky designed the power curve within the software to deliver the 108Nm smoothly, allowing you as the rider to soft pedal around tight switchbacks or drop the hammer through a chunky, punchy, portion of trail.
RIDE-4™ adjustment system
The RIDE-4 adjustment system allows riders to quickly fine-tune their geometry with a single Allen key. Four configurations are possible thanks to one rotating chip.
FORM™
Alloy FORM™ tubesets utilise premium materials to meet Rocky's strict requirements. Each FORM™ tube that Rocky create is engineered for its specific purpose within the frame, ensuring optimise strength, weight, and ride quality.
Size Specific Tune
Size Specific Tune ensures that riders of all sizes get the right balance of small-bump compliance, mid-stroke support, and end-stroke progressiveness.
Rocky Mountain's design team does custom shock tunes based on real world field testing, and adjusts each tune for specific frame sizes.
Two-position axle The two-position axle allows the rider to choose a short or long rear-centre length that suits their personal preferences.
SPECIFICATIONS
| Component | Specification |
|---|---|
| Frame | FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry + Suspension Rate | 140mm Travel. FORM™ Alloy Rear Triangle |
| Fork | RockShox 35 Gold RL 150mm | 44mm Offset |
| Front Travel | 150 |
| Shock | RockShox Deluxe Select R | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 210x55mm | Size-Specific tune in FAQ |
| Rear Travel | 140 |
| Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m |
| Handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Grips | Rocky Mountain Lock On Light |
| Brakes | Shimano MT4120 4 Piston | Resin Pads | F:Shimano RT30 203mm | R:Shimano RT30 203mm |
| Shifters | Shimano Deore 11spd |
| Rear Derailleur | Shimano Deore 11spd |
| Cranks & Chainring | Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM - MD = 165mm | LG - XL = 170mm |
| Bottom Bracket | Shimano SM-BBMT500 |
| Cassette | Shimano Deore 11-51T 11spd |
| Chain | KMC X11-1 |
| Front Hub | Rocky Mountain Sealed Boost 15mm |
| Rear Hub | Novatec D462 Sealed Boost 148mm |
| Spokes | 2.0 Stainless |
| Rims | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape / Valves Incl |
| Tires | F: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready |
| Seatpost | Rocky Mountain Toonie Drop Composite 30.9mm | SM = 125mm | MD = 150mm | LG - XL = 170mm |
| Saddle | WTB Volt 142 |
| Drive System | Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada |
| Battery | 720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A) |
| Remote | Rocky Mountain Micro Remote |
| Display | Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
| Charger | Rocky Mountain Powerplay Charger | 2A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4) |
| Weight | This information isn't available yet. We will update the weight of this model as soon as possible |
| Notes | We make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification. |
-
